    IEC Standard Battery Thermal Shock Test Chamber For UL KP-3020-B

    Ask Lasest Price
    Brand Name : KingPo
    Model Number : KP-3020-B
    Certification : iso9001
    Price : To be quoted
    Payment Terms : TT
    Delivery Time : 35 working days
    Supply Ability : 3 sets per month
    • Product Details
    • Company Profile

    IEC Standard Battery Thermal Shock Test Chamber For UL KP-3020-B


    Thermal Shock Test Chamber For UL And IEC Standard


    1. Quick Details


    Alternative nameBattery Thermal Shock Test Chamber
    FunctionTest battery safety capability after suffering impact of hot air
    TypeClimatic simulating test chamber
    Weight80kg
    Internal spaceW65*H92*D53cm
    Corresponding test standardUL2054-2008, UL1642, SJ/T11170, IEC62133, SJ/T11169, GB/T18287, QC/T743, QC/T744

    2. Description


    The battery thermal shock test chamber is used to test safety capability after suffering hot air shock.

    The temperature will be raised at certain speed at certain time, apply hot air cyclic system to ensure average distribution of working temperature.


    3. Features


    a. The low air pressure tester is used for testing safety capability of lithium battery.

    b. The tester is simulating battery suffering environment of hot air shock.

    c. Test result is non explosion, no fire, non air leaking, non electrolyte leakage for the qualified battery.


    4. Specifications


    ModelKP-3020-B
    Temperature rangeNormal temperature to 200℃
    Temperature accuracy0.1℃
    Temperature stability±1.0℃
    Temperature uniformity±2℃
    Temperature raising time(5±2)℃/min (temperature average raising)
    Temperature- controlled meterProgrammable, time control for temperature raising time
    Internal dimension W*H*D mmW40*H40*D45cm
    External dimension W*H*D mmW65*H92*D53cm
